450mm /BTO-22 – Razor Barrier Concertina Barbed Wire

Packaging Details: Water Proof Paper, Wooden Case And Pallet
Supply Ability: 2000000 Piece/Pieces per Week
Delivery Time: 15 Days
Port: Tianjin Xingang

OVERVIEW

Concertina Razor Wire Specifications

Type:                                            BTO-22
Thickness of the steel plate:  0.5mm
Wire Diameter:                           2.5mm
Blade length:                               22mm
Blade width:                                15mm
Blade spacing:                            34mm
Coil Diameter:                             450mm-1500MM
Coil Length:                                 8Mtr – 15Mtr

Concertina BTO-22 is manufactured in stainless steel or HOT dipped galvanized steel
Razor wire Other Specifications: BTO-12, BTO-15, BTO-18,BTO-30, CBT-60, CBT-65.

450mm /BTO-22 – Razor Barrier Concertina Barbed Wire

Reinforced Barbed Tape 65 /CBT-65

Concertina Super H is defined by its blade 65 mm wide (this type of blade next to Concertina L type are the two models with more blade length) belongs to the most aggressive models concertinas, with a space between blades of 100 mm and 8 points in each blade creating a hook effect. Concertina Super H contains extra reinforcement, this reinforcement situated on both sides of the wire and with a height of 2 mm, provides extra reinforcement concertina to increase its strength.
The diameter of this type of concertina is 450 mm – 1500 mm, but we have different action on other models of concertinas, special measures such as 630, 640 or 955 mm.
Concertina Super H made ​​of stainless steel or galvanized wire high strength 1400 – 1600 Mpa.
The sectors requiring this type of concertinas are places with high levels of security, such as prisons or military bases offer.

Concertina Super H, 65 mm long blade 8 point hook creating an effect, particularly poignant. Extra center reinforcement.

  • Razor wire cross section profile
    The cross section of razor wire shows the blade and high tensile core wire profiles.
Razor wire Other Specifications:   BTO-12, BTO-15, BTO-18, BTO-22, BTO-30, CBT-60
Blade spec Blade profile Blade thickness
mm
Core wire diameter
mm
Blade length
mm
Blade width
mm
Blade space
mm
BTO-10 This is BTO-10 blade profile. 0.5±0.05 2.5±0.1 10±1 13±1 26±1
BTO-12 This is BTO-12 blade profile. 0.5±0.05 2.5±0.1 12±1 15±1 26±1
BTO-18 This is BTO-18 blade profile. 0.5±0.05 2.5±0.1 18±1 15±1 33±1
BTO-22 This is BTO-22 blade profile. 0.5±0.05 2.5±0.1 22±1 15±1 34±1
BTO-28 This is BTO-28 blade profile. 0.5±0.05 2.5 28 15 45±1
BTO-30 This is BTO-30 blade profile. 0.5±0.05 2.5 30 18 45±1
CBT-60 This is BTO-60 blade profile. 0.6±0.05 2.5±0.1 60±2 32±1 100±2
CBT-65 This is BTO-65 blade profile. 0.6±0.05 2.5±0.1 65±2 21±1 100±2
  •  Mateiral

Concertina CBT-65 is manufactured in stainless steel or galvanized steel, in the following characteristics:

  1. Stainless Steel EN 1.4016 – AISI 430
  2. Stainless Steel EN 1.4301 – AISI 304
  3. Stainless Steel EN 1.4401 – AISI 316
  4. Heavy Galvanized steel Z230 – Z275 (G75-G90)
  5. High Tensile: 1300 – 1600 MPa
  6. Nº Coils: 55±1

The razor wire coils are manufactured using mild steel wire and are equipped with sharp blades. It adds an anti-climb quality to almost all fences.

Galvanized razor wire often combines with chain link fence, field fence, welded wire fence, walls and gates to provide high security. Widely used in residential, commercial, military, garden, boundary and prisons.

Advantages of galvanized razor wire:

  • Zinc coating protects inside steel wire;
  • Sharp blades scares enemies away;
  • Silvery appearance warning people not climbing.
  • Related cheap price
